When working with relays in electronic circuits, one important detail often overlooked is the need to protect other components from voltage spikes generated when the relay coil is turned off. This phenomenon occurs because a relay coil is essentially an inductor, and inductors resist changes in current. When current flowing through the coil is suddenly interrupted—such as when the switching transistor or driver circuit stops supplying power—the magnetic field around the coil collapses rapidly. This collapse induces a high voltage spike in the opposite direction, which can reach hundreds of volts. Without protection, this spike can damage sensitive components like transistors, microcontrollers, or integrated circuits connected to the relay control circuit.

To prevent this damage, engineers use a technique called relay coil suppression.

The most common and effective method involves placing a diode across the relay coil terminals.

Positioned so that the cathode attaches to the supply voltage terminal and the anode to ground.

This diode is called a flyback diode, freewheeling diode, or clamp diode.

When the relay is energized, the diode is reverse biased and has no effect on the circuit.

Upon de-energization, the induced polarity switches and activates the diode.

Creating a controlled feedback path where energy dissipates gradually without damaging components.

By circulating current in a loop, peak voltages are clamped to safe, predictable values.

The diode’s specifications must match the relay’s electrical demands.

It must be rated for at least the continuous current drawn by the relay coil.

Its reverse breakdown voltage must exceed the circuit’s maximum supply rail.

A common choice is the 1N4007 diode for low to medium current relays.

When rapid coil deactivation is required, faster recovery diodes improve response time.

To accelerate current decay, engineers sometimes add a resistor in series with the flyback diode.

Though this increases the voltage spike slightly and must be balanced with component ratings.

Another method of suppression involves using a metal oxide varistor or an RC snubber network.

They are preferred in applications where rapid relay release is critical.

Such as in circuits requiring fast relay release times.

However, for most general purpose applications, the simple and inexpensive flyback diode remains the preferred solution due to its reliability and effectiveness.

In summary, adding a flyback diode across a relay coil is a simple but essential practice.

It prevents semiconductor failure, reduces maintenance, and enhances circuit durability.

Always include this protection when driving relay coils with transistors or other semiconductor switches.

A trivial cost for vastly improved circuit resilience.
